Mastervolt PowerCombi 12V – 1200W – 50 Amp (120V) [36211200]

PowerCombi 12V – 1200W – 50 Amp (120V)

Simple. Independent. Flexible.

The PowerCombi is a pure sine wave inverter/charger offering grid quality AC power and battery charging in one low profile design. Designed to be an independent inverter / charger, it yet can easily be integrated into a MasterBus network (with additional interface).

With a built-in transfer switch, 2x surge for 3 seconds and on-site dipswitch programming—the PowerCombi offers simple installation with multiple operating modes, and can charge various battery chemistries—including a custom profile for use with Li-ion.

Full certifications make it perfect for use in RV’s, boats, and specialty vehicles. Add a battery temperature sensor (BTS), remote display and a communication interface for custom applications.

Specifications:

• Outlet Qty: Hardwire
• Inverter Output Voltage: 120v
• Inverter Input Voltage: 12v
• Inverter Cont. Output Wattage: 1200w
• Charger Output Voltage: 12v
• Charger Output – Amps: 50a
• Charger Input – Voltage: 120v
• Box Dimensions: 7″H x 12″W x 19″L WT: 7.45 lbs
• UPC: 816882022579

Owner’s Manual (pdf)
