Raymarine Bronze Thru-Hull Transducer w/ Fairing Block [A66090]

Raymarine B744V Bronze Thru-Hull Transducer w/ Fairing Block

• Compatible hull material: wood, and fiberglass
• Frequency: 200/50 kHz
• Cable Length = 9.1m/30ft
• Power: 500W RMS (depending on connected SONAR)
• Hole diameter for installation: 2″
• Self-sealing removable paddle wheel insert
• High speed fairing block included

FOR RAYMARINE NEW A,C,E SERIES DISPLAYS

Specifications:

• Speed Included: Yes
• Temperature: Yes
• Mounting Style: Thru-Hull
• Imagining: Standard
• Chirp: No
• Cable Length (Feet): 30′
• Box Dimensions: 4″H x 12″W x 16″L WT: 7.4 lbs
• UPC: 723193660904

Owner’s Manual (pdf)
Brochure (pdf)
